Production Lines
Wall Putty & Car Putty Production Line
Wall Putty & Car Putty Production Line: Complete wall putty and car putty production lines from 500L lab batches to 10,000L platform systems. High-viscosity mixing, vacuum degassing, extrusion and filling configured for your formulation. Capacity range 500L - 10,000L per batch. Typical applications: Construction Chemicals, Automotive Coatings, Powder Processing, Packaging, Wood Coatings.
Complete wall putty and car putty production lines from 500L lab batches to 10,000L platform systems. High-viscosity mixing, vacuum degassing, extrusion and filling configured for your formulation.
The POLYC Wall Putty & Car Putty Production Line is a complete turnkey system engineered for construction putties, automotive body fillers and high-viscosity paste products, handling the full process from raw-material feeding and powder dosing through high-torque mixing, vacuum degassing, extrusion and final filling. Configured from 500 L lab batches to 10,000 L platform systems, it serves both dry powder blends and bubble-free paste routes with one accountable package.
Key Facts
- Equipment Type
- Production Lines
- Capacity / Batch Range
- 500L - 10,000L per batch
- Max Viscosity
- dry powder to over 500,000 cP paste
- Typical Applications
- Construction Chemicals, Automotive Coatings, Powder Processing, Packaging
Request a Quote
Response within 24 hours · Engineering consultation · Application review available
Where the Putty Line Performs Best
Industry ApplicationsDry-powder blending and high-torque paste mixing on one configurable platform make the POLYC line the right choice for putty and filler manufacturers serving construction and automotive markets.
🏙
Wall Putty & Skim Coat
Dry powder wall putty and skim coat production.
🧾
Tile Adhesive & Grout
Cement-based tile adhesive and grout blending.
🏙
Gypsum & Cement Putty
Gypsum and cement-based putty blending.
🚗
Car Body Putty
Car body putty and polyester filler production.
🏘
Wood Filler & Putty
Wood filler and putty manufacturing.
🔨
High-Viscosity Paste
Industrial paste and filler extrusion.
Putty Line at a Glance
Line Overview3,000–60,000t/yr
Line Capacity
500–6,000L
Batch Size
>500,000cP
Viscosity Range
4mixers
Ribbon/Paddle/Plough/Planetary
Key Design Features
EngineeringClean🧼
Dust-Controlled Dosing
- Powder dosing and conveying
- Bag or cartridge collector
- Safer operator conditions
Stiff⚙️
High-Torque Mixing
- For stiff paste and putty
- Ribbon, paddle, plough
- Planetary option available
Modular🔧
Multi-Mixer Options
- Ribbon / paddle / plough
- Matched to formulation
- Dry or paste routes
Bubble-Free💧
Vacuum Degassing
- Optional vacuum function
- Smooth paste products
- Jacketed temperature control
Fill🧾
Extrusion & Filling
- Cartridge, pail, drum
- High-viscosity discharge
- Sized to your formats
Repeatable⚖️
Recipe Batching
- Recipe-controlled batching
- Batch documentation
- Coordinated controls
Applications by Industry
Selection| Industry | What the POLYC Putty Line Delivers |
|---|---|
| Construction Chemicals | Wall putty and skim coat powder production |
| Automotive Coatings | Car body putty and polyester filler production |
| Construction Chemicals | Tile adhesive and grout manufacturing |
| Construction Chemicals | Gypsum and cement-based putty blending |
| Construction Chemicals | Water-based and solvent-based putty mixing |
| Construction Chemicals | Dry mortar and plaster production |
| Powder Processing | Automatic powder dosing and packing |
| Packaging | Cartridge and pail filling of putty |
| Wood Coatings | Wood filler and putty production |
| Industrial Coatings | High-viscosity paste and filler extrusion |
Choosing the Right Putty Production Line
How to Choose1
Decide the route
Choose between dry powder and paste processing first, because ribbon, paddle, plough or planetary mixers differ fundamentally between the two routes.
2
Size the torque and dust
Size mixing torque from the stiffest formulation, and plan dust collection together with the dosing stage rather than adding it afterwards.
3
Confirm layout and expansion
Plan floor-type or platform layout, automation level, and future expansion so the line grows with your business.
Related Technical Guides
Guides
SelectionHigh Viscosity Mixer Selection Guide
PowderPowder Mixer Selection: Ribbon, Paddle, or Planetary?
SpecsHigh Viscosity Mixer Specs and Selection Guide
ComparePlanetary Mixer vs Ribbon Blender Guide
Need a wall putty or car putty production line configured for your plant?
Request a QuotationDescription
How it works
The POLYC Wall Putty & Car Putty Production Line is a complete turnkey system that moves each batch from raw-material feeding and powder dosing through high-torque mixing, vacuum degassing, extrusion and filling. POLYC designs, manufactures, installs and commissions the whole line as one accountable package.
Configurations cover dry wall putty and skim coat, tile adhesive and grout, gypsum and cement-based putty, car body putty and polyester filler, wood filler and high-viscosity industrial paste, with ribbon, paddle, plough or planetary mixers matched to the formulation. Vacuum degassing and jacketed temperature control deliver smooth, bubble-free paste products.
Central PLC controls with recipe management document every batch, while modular floor-type and platform layouts, dust collection and future expansion are engineered together so the line grows with your business.
INDUSTRIES THIS MACHINE SERVES
Industries we serve
PUTTY LINE VS STANDALONE MIXER
Turnkey line or individual mixer?
| Dimension | POLYC Putty Line | Standalone Mixer |
|---|---|---|
| Scope | Feeding to filled pails | Single mixing step |
| Annual capacity | 3,000 - 60,000 t/yr | Limited by manual handling |
| Batch size | 500 - 6,000 L / mixer | Depends on unit only |
| Viscosity | dry powder to >500,000 cP | Same mixer, less integration |
| Vacuum degassing | optional, integrated | Separate, manual |
| Filling | cartridge / pail / drum | External, manual |
| Accountability | One supplier package | Multiple vendors |
Read the full comparison guide: High Viscosity Mixer Selection Guide
Process Engineering
Working Principle
- 1
A putty production line combines powder dosing and blending for dry formulations with high-torque mixing for paste products.
- 2
Dry wall putty is produced by blending cement or gypsum, fillers and additives in a ribbon, paddle or plough mixer to a homogeneous powder.
- 3
Paste and car body putty are produced by dispersing pigments and fillers into resin under higher torque.
- 4
Both routes finish with filling into pails, cartridges or drums.
Equipment Benefits
Equipment Advantages
- ✓
Vacuum mixing removes entrapped air for smooth, bubble-free putty.
- ✓
Jacketed tanks control temperature during high-shear dispersion.
- ✓
Modular design supports both floor-type and platform layouts.
- ✓
Complete turnkey package from raw material feeding to final filling.
Technical Data
Technical Specifications
| Parameter | Value |
|---|---|
| Line capacity | 3,000 - 60,000 tonnes per year depending on configuration |
| Batch size | 500 - 6,000 L per mixer |
| Mixer type | Ribbon, paddle, plough or planetary depending on product |
| Viscosity range | dry powder to over 500,000 cP paste |
| Control system | PLC with recipe management |
| Contact material | Stainless steel or carbon steel with wear protection |
| Dust control | Bag filter or cartridge collector |
PRODUCT INQUIRY
Get Price & Specs for This Product
Tell us your material and capacity, our engineer will reply within 24 hours.
Thank you! Our engineer will contact you within 24 hours.
Equipment Guidance
Frequently Asked Questions
What is a POLYC wall putty and car putty production line and what does it include?
A POLYC wall putty and car putty production line is a complete turnkey system covering raw-material feeding and powder dosing, high-torque mixing, vacuum degassing, extrusion and filling. POLYC configures it from 500 L lab batches to 10,000 L platform systems and supplies both dry powder blends and bubble-free paste routes as one accountable package.
What capacity and batch sizes can the line handle?
Line capacity is configurable from 3,000 to 60,000 tonnes per year, with 500 to 6,000 L per mixer. The system scales from small-batch floor-type units to large-batch platform systems based on your production needs.
Which mixer types are offered?
Ribbon, paddle, plough or planetary mixers are offered and matched to the formulation. Dry powder blends and high-torque paste products use fundamentally different mixer types, so the route is chosen first.
What viscosity and vacuum capability does it support?
The line handles everything from dry powder to paste above 500,000 cP, with an optional vacuum function for bubble-free paste products and jacketed tanks that control temperature during high-shear dispersion.
Which products can the line produce?
Configurations serve wall putty and skim coat, tile adhesive and grout, gypsum and cement-based putty, car body putty and polyester filler, wood filler and putty, water-based and solvent-based putty, dry mortar and plaster, and high-viscosity industrial paste and filler.
How is dust controlled and operator safety handled?
Dust-controlled powder dosing and conveying use a bag filter or cartridge collector, and dust collection is planned together with the dosing stage rather than added afterwards.
How do I size and select the right putty line?
First decide between dry powder and paste processing because the mixer types differ fundamentally. Then size mixing torque from the stiffest formulation and plan dust collection with the dosing stage, and confirm layout, automation and future expansion.
Does POLYC provide installation, commissioning and future expansion support?
Yes. POLYC delivers the whole line design, equipment manufacturing, installation and commissioning as one package, and engineers modular floor-type and platform layouts, utilities and future expansion together so the line grows with your business.
Industry Applications
Applications
Construction Chemicals
wall putty and skim coat powder production
Automotive Coatings
car body putty and polyester filler production
Construction Chemicals
tile adhesive and grout manufacturing
Construction Chemicals
gypsum and cement-based putty blending
Construction Chemicals
water-based and solvent-based putty mixing
Construction Chemicals
dry mortar and plaster production
Powder Processing
automatic powder dosing and packing
Packaging
cartridge and pail filling of putty
Wood Coatings
wood filler and putty production
Industrial Coatings
high-viscosity paste and filler extrusion
WHY POLYC MACHINE
Built on Engineering Excellence Since 2006
Every machine is designed by our in-house R&D team, built in our own factory, and supported by the same team that has delivered over 8,000 systems worldwide.
ISO 9001 & CE Certified
Manufactured under an ISO 9001 quality management system. All machines comply with CE directives, with EC Declaration of Conformity for every order.
Experience Since 2006
Since 2006, POLYC has engineered wet grinding, dispersing and mixing systems for global manufacturers.
3-Year Warranty
Every machine carries a 3-year warranty with ongoing spare-parts supply and technical support after delivery.
30-Day Delivery
Standard models ship within 30 days of order confirmation. Custom-engineered lines are scheduled against your project timeline.
Free Installation Guidance
Free installation guidance and operator training are included with every machine, covering commissioning and safe start-up.
Custom Engineering
From lab-scale 0.5L to 12,000L production systems. Material testing, configuration and process design included.
24-Hour Response
Engineering consultation within 24 hours. Application review, technical specs and quotation delivered fast.
Global Shipping
Export-ready packaging with full documentation. DDP/FOB/CIF terms available for 80+ countries.
Lifetime Technical Support
Genuine spare parts, remote diagnostics and lifetime technical support for every machine we build.
