Mixers
Lacquer-mixer: Our PLM Lacquer Mixer is concentric design equipment, suitable for stirring and mixing high viscosity materials, such as lacquer (stone-like paint), texture coa. Capacity range 100 - 12,000 L. Typical applications: Wood Coatings, Industrial Coatings, Automotive Coatings, Printing Inks, Plastic Coatings.
Our PLM Lacquer Mixer is concentric design equipment, suitable for stirring and mixing high viscosity materials, such as lacquer (stone-like paint), texture coa
A lacquer mixer is designed for blending lacquers, varnishes and clear coatings where thorough but gentle mixing is needed without aeration or shear damage.
Response within 24 hours · Engineering consultation · Application review available
Lacquer-mixer is applied across multiple industries. The configuration is matched to your material, fineness target and batch volume.
lacquer and varnish blending at 200-3000 L without air entrainment
finished coating blending at ≤50,000 cP
refinish paint mixing with ±2% viscosity adjustment
varnish and ink adjustment at 100-2000 L
coating thinning and blending at 200-2000 L
topside coating blending at 500-5000 L
Gentle agitation avoiding aeration of lacquers and varnishes
Solvent-compatible seals and construction
Effective blending of base, thinner and additives
Slow-speed operation preventing shear-induced defects
Suitable for clear coats where appearance is critical
Simple cleaning between clear and pigmented products
| Industry | Typical Application |
|---|---|
| Wood Coatings | lacquer and varnish blending at 200-3000 L without air entrainment |
| Industrial Coatings | finished coating blending at ≤50,000 cP |
| Automotive Coatings | refinish paint mixing with ±2% viscosity adjustment |
| Printing Inks | varnish and ink adjustment at 100-2000 L |
| Plastic Coatings | coating thinning and blending at 200-2000 L |
| Marine Coatings | topside coating blending at 500-5000 L |
| Corrosion Protection | primer thinning and homogenisation at 300-4000 L |
| Construction Chemicals | solvent-based coating blending at 200-3000 L |
| Cosmetics | nail lacquer and low-viscosity blending at 50-500 L |
| Adhesives & Sealants | solvent-based adhesive standardisation at 200-3000 L |
Select vessel volume and agitator type from storage, let-down, tinting, or gentle-mixing duty.
Confirm viscosity, density, turnover time, heating or cooling needs, and discharge arrangement.
Specify product-contact material, surface finish, cover, controls, and hazardous-area requirements.
Need help specifying the Lacquer-mixer for your process?
Request a QuotationThis machine is engineered for the following viscosity band. The exact model and blade configuration are selected after reviewing your material and process.
| Typical viscosity | low to medium viscosity |
|---|---|
| Typical materials | Wood Coatings |
Description
A lacquer mixer is designed for blending lacquers, varnishes and clear coatings where thorough but gentle mixing is needed without aeration or shear damage. It is used in wood coating, automotive refinish and industrial finishing plants. POLYC supplies lacquer mixers with slow-speed agitation and so Gentle agitation avoiding aeration of lacquers and varnishes Solvent-compatible seals and construction Effective blending of base, thinner and additives Typical applications include Wood Coatings, Industrial Coatings, Automotive Coatings, Printing Inks. Select vessel volume and agitator type from storage, let-down, tinting, or gentle-mixing duty.
INDUSTRIES THIS MACHINE SERVES
High-viscosity mixing for adhesives, sealants, and polymer compounds.
Learn more →High-viscosity cathode/anode slurry mixing for lithium battery production.
Learn more →Powder and paste mixing for food, pharmaceutical, and chemical applications.
Learn more →TYPICAL PERFORMANCE REFERENCE
| Material Type | Viscosity Range | Recommended Machine Type | Batch Size |
|---|---|---|---|
| Low-viscosity liquid | < 10,000 cP | Double shaft / high-speed | 100-2,000 L |
| Medium-viscosity paste | 10,000-100,000 cP | Planetary mixer | 50-1,000 L |
| High-viscosity compound | > 100,000 cP | Planetary / kneader | 50-500 L |
Typical reference values only. Actual results depend on formulation, bead material, and process conditions. Material testing is recommended before final selection.
MACHINE COMPARISON
| Parameter | Lacquer-mixer | Planetary Mixer | Butterfly Double Shaft Mixer | Concentric Double Shaft Mixer |
|---|---|---|---|---|
| Chamber / capacity | 100 - 5,000 L | 5 - 3,000 L | 200 - 5,000 L | 300 - 6,000 L |
| Motor power | 1.5 - 30 kW | 4 - 110 kW | 11 - 90 kW | 15 - 110 kW |
| Media / agitation | Propeller, paddle or anchor at low speed | Single, double or triple planetary agitators | Butterfly scraper plus high-speed dispersing shaft | Concentric anchor plus high-speed dispersing shaft |
| Viscosity | low to medium viscosity | up to over 1,000,000 cP | up to approximately 150,000 cP | up to approximately 200,000 cP |
| Contact material | Stainless steel 304 / 316L with solvent-compatible seals | Stainless steel 304 / 316L | Stainless steel 304 / 316L | Stainless steel 304 / 316L |
Read the full comparison guide: High Viscosity Mixer Selection Guide
Process Engineering
A paddle, propeller, or cup-type agitator circulates finished liquid through the vessel at controlled speed.
The low-shear flow maintains uniformity, supports tinting or let-down, and limits unnecessary air entrainment.
A jacket and controlled discharge can be integrated where temperature or transfer management is required.
Equipment Benefits
Gentle circulation limits unnecessary shear and air entrainment.
Multiple agitator styles suit storage, tinting, and let-down duties.
Jacket, cover, and discharge options integrate with the production line.
Simple construction supports inspection and cleaning.
Technical Data
| Parameter | Value |
|---|---|
| Working capacity | 100 - 5,000 L |
| Motor power | 1.5 - 30 kW |
| Agitation | Propeller, paddle or anchor at low speed |
| Viscosity range | low to medium viscosity |
| Contact material | Stainless steel 304 / 316L with solvent-compatible seals |
| Options | Jacketed vessel, variable speed, load cells |
| Discharge | Bottom outlet to filling |
PRODUCT INQUIRY
Tell us your material and capacity, our engineer will reply within 24 hours.
Equipment Guidance
The Lacquer-mixer is built for Wood Coatings, Industrial Coatings, Automotive Coatings. It is selected when the batch has to be blended homogeneously without the shear damage a disperser would cause.
It works up to low to medium viscosity. Product-contact parts are Stainless steel 304 / 316L with solvent-compatible seals.
The agitator geometry keeps the whole batch moving rather than only the zone around the shaft, so colour, filler and additive distribution stay consistent from batch to batch.
Capacity is 100 - 5,000 L, with motor power 1. Vessel size is matched to the batch and the available floor space.
Bottom discharge, side discharge and hydraulic discharge arrangements are offered, with vacuum and jacket options where the formulation requires them.
Industry Applications
lacquer and varnish blending at 200-3000 L without air entrainment
finished coating blending at ≤50,000 cP
refinish paint mixing with ±2% viscosity adjustment
varnish and ink adjustment at 100-2000 L
coating thinning and blending at 200-2000 L
topside coating blending at 500-5000 L
primer thinning and homogenisation at 300-4000 L
solvent-based coating blending at 200-3000 L
nail lacquer and low-viscosity blending at 50-500 L
solvent-based adhesive standardisation at 200-3000 L
